key:

1. Air filter casing
2. Secondary air valve
3. Secondary air system pipe
4. Secondary air system inlets on the engine

• Two auxiliary air inlets have been included in the cylinder head which, in combination with the injection system with oxygen sensor and three-way catalytic converter, ensure compliance with severe new Euro 4 emissions regulations
• Undo the screws fastening the reed valve cover.

• Remove the reed valve cover

• Remove the reed valve.

• Remove the flame trap.

• A valve controlled by the engine ECU is installed under the tank, which allows air to flow towards the cylinders via two flexible hoses.

• This valve is connected directly to the filter box via a flexible hose.
